Axial LED RGB Common Anode PLCC-4 Tri Color LED Red Green and Blue Luminous Diode
Tri Color LED Red Green and Blue Axial LED RGB Common Anode PLCC-4 Luminous Diode
Product Description of RGB Axial SMD LED
Absolute Maximum rating of RGB Axial SMD LED:(Ta=25°C)
| Parameter | Symbol | Value | Unit |
| Forward current | If | 30 | mA |
| Reverse Voltage | Vr | 5 | V |
| Power dissipation | Pd | 60 | mW |
| Operationg temperature | Top | -40∼+85 | °C |
| ESD(Human-body mode | -- | 2 | KV |
| Storage temperature | Tstg | -40∼+85 | °C |
| Peak pulsing current(1/8 duty f=1kHz | lfP | 125 | mA |
Electrical characteristics of RGB Axial SMD LED:(Ta=25°C)
| Parameter | Test condition | Symbol | Value | Unit |
| color | Min | Typ | Max |
| Dominant wavelength | If=20mA | λp | red | 620 | --- | 630 | nm |
| green | 520 | --- | 530 |
| blue | 460 | --- | 470 |
| Forward voltage | If=20mA | Vf | red | 1.7 | --- | 2.2 | v |
| green | 2.3 | --- | 3.0 |
| blue | 2.3 | --- | 3.0 |
| Light intensity | If=20mA | Iv | red | 120 | --- | 450 | mcd |
| green | 450 | --- | 1000 |
| blue | 100 | --- | 300 |
| Viewing angle at 50% lv | If=10mA | 2θ1/2 | | | 120 | | Deg |
| Resverse current | Vr=5v | Ir | | | | 10 | uA |
Outline dimension of RGB Axial SMD LED:
Feature of RGB Axial SMD LED:
1. Long life span
2. Light decay is small
3. Good quality
4. Energy saving and environmental protection
5. Price is competitive
6. ROHS certification
Application of RGB Axial SMD LED:
1. Car dashboard, stop lights, turn signals
2. Liquid crystal display
3. Industrial electronics, etc
